Weird that this engine doesn't have rings on it?

Welcome to RCTalk

Come join other RC enthusiasts! You'll be able to discuss, share and private message with other members of our community.

coldvod

RCNT Qualifier
Messages
160
Reaction score
88
Location
Ontario, Canada
RC Driving Style
  1. Bashing
  2. Crawling
  3. Scale Builder
Its a magnum .21 that was bought before the 90s it was made by thunder tiger. Just thought i'd be fun to show off some old engine parts


Attachments

  • 20220519_233202.jpg
    125.1 KB · Views: 19
  • 20220519_233154.jpg
    160.5 KB · Views: 19

nitropro

RC Newbie
Messages
14
Reaction score
8
Location
Cape Town, South Africa
RC Driving Style
  1. Bashing
That is awesome to see old engines still being loved. I don't think any nitros that small have rings. Hope that helped somewhat.


coldvod

RCNT Qualifier
Messages
160
Reaction score
88
Location
Ontario, Canada
RC Driving Style
  1. Bashing
  2. Crawling
  3. Scale Builder
That is awesome to see old engines still being loved. I don't think any nitros that small have rings. Hope that helped somewhat.
I thought my redcat sh 21 had rings which is why i mentioned it


nitropro

RC Newbie
Messages
14
Reaction score
8
Location
Cape Town, South Africa
RC Driving Style
  1. Bashing
Oh ok, no worries. Your redcat engine definitely doesn't, just a different piston design may have lead you to think that.

Happy rc'ing!


coldvod

RCNT Qualifier
Messages
160
Reaction score
88
Location
Ontario, Canada
RC Driving Style
  1. Bashing
  2. Crawling
  3. Scale Builder
Oh ok, no worries. Your redcat engine definitely doesn't, just a different piston design may have lead you to think that.

Happy rc'ing!
Thanks i might've misremebered since its been a feq months. If you want to see this engine run by the way ill be posting a video whenever i get around to ordering a bump box ( i have two of these and one them is fully rebuilt )


coldvod

RCNT Qualifier
Messages
160
Reaction score
88
Location
Ontario, Canada
RC Driving Style
  1. Bashing
  2. Crawling
  3. Scale Builder
Cool, look forward to seeing an update!
I also have the manual and the box warraty stickers everything even a receipt. 4 gallons for 68cad$


Attachments

  • 20220520_123923.jpg
    197.5 KB · Views: 13
  • 20220520_123926.jpg
    157.1 KB · Views: 13
  • 20220520_123929.jpg
    168 KB · Views: 13
  • 20220520_123933.jpg
    144.9 KB · Views: 15
  • 20220520_123935.jpg
    179 KB · Views: 14
  • 20220520_124001.jpg
    228 KB · Views: 13
  • 20220520_123931.jpg
    188.5 KB · Views: 16

olds97_lss

RCNT VIP
Supporter
Excellence Award
Build Thread Contributor
Messages
20,534
Reaction score
2,222
Location
Dekalb, IL
RC Driving Style
  1. Bashing
Quite a few of the nitro pistons I"ve had had rings cut into the piston. Not sure what their purpose was, maybe to try and hold oil? They weren't actual mechanical/spring rings like a normal engine, just a detent in the piston. Well... I could have swore some of them did anyway.

This is the only piston photo I have from one of the many engines I've had over the years... it didn't seal well anymore. lol! It was an OS 21RG:


One of the ball bearings in the rear bearing split in half and went through the engine like a hammer drill. Made a mess out of the poor thing.


coldvod

RCNT Qualifier
Messages
160
Reaction score
88
Location
Ontario, Canada
RC Driving Style
  1. Bashing
  2. Crawling
  3. Scale Builder
Quite a few of the nitro pistons I"ve had had rings cut into the piston. Not sure what their purpose was, maybe to try and hold oil? They weren't actual mechanical/spring rings like a normal engine, just a detent in the piston. Well... I could have swore some of them did anyway.

This is the only piston photo I have from one of the many engines I've had over the years... it didn't seal well anymore. lol! It was an OS 21RG:


One of the ball bearings in the rear bearing split in half and went through the engine like a hammer drill. Made a mess out of the poor thing.
I thought when I was taking apart my redcat engine it had a small ring. After taking the piston out i think you're right. I wouldn't have thought that they would make a detent. It seems useless
