Well guys, I have a brand new EVX 2 and yes, it is the version 2. This is the brand new type of EVX being the old one is getting discontinued. This ESC has never been opened from the package Traxxas sent me. I am also including 2 male deans connectors with it.
The EVX 2 includes the set of instructions as well. Here are the specs:
EVX-2 SPECIFICATIONS
Input voltage: 6-14 cells (7.2 to 16.8 volts DC)
Case Size: 2.27”W x 2”D x 1.05”H
Weight: 3.6 ounces
Motor Limit (540 size): 10-turns
Motor Limit (550 size): 12-turns
On-Resistance (@Trans)–FWD/REV: 0.004 Ω / 0.004 Ω
Rated Current–FWD/REV: 180 amps / 180 amps
Braking Current: 360 amps
Continuous Current
(@100°F amb.): 30 Amps
Reverse Delay: None
BEC Voltage: 6.0 volts DC
BEC Current: 2.5 amps
Power Wire: 14 Gauge / 3"
Input Harness Wire: 26 Gauge / 9.5"
Motor Wires: 14 Gauge / 9"
Transistor Type: MOSFET
PWM Frequency: 1700 Hz
Thermal Protection: Thermal shutdown
Profile selection: Sport Mode:
100% fwd, 100% brakes, 100% rev
Race Mode:
100% fwd, 100% brakes, no rev.
Training Mode:
50% fwd, 100% brakes, 50% rev.
Single-button setup: Yes, Traxxas EZ-Set®
Price is $130 shipped to your door, USPS Priority Mail. This gives you a chance to get an awesome ESC, before it is even officially released for sale by Traxxas!
I accept Paypal, Money Order, Cashiers Checks, and Personal Checks once cleared.
Feel free to ask any questions!
